FR-N1XD4-AR 2x25 NF C33-209
FR-N1XD4-AR 2x25 NF C33-209
The low-carbon power grid cables for distribution public networks (buried and aerial), 100% manufactured in France (plant Jeumont 59), guarantee a minimum 35% reduction in greenhouse gas emissions compared to standard cables.
This offer is built on the guaranteed use of low-carbon aluminium and recycled plastic, as well as the use of renewable or decarbonised energies in manufacturing the cables.
Nexans provides all the environmental data for its products (PEP Ecopassport®).
Read more- Nexans ref. : 10044010
- Country ref. : 01123070
- EAN : 3427670000319
Description
Description
Standards
-
InternationalIEC 60298
-
NationalNF C11-201; NF C32-013; NF C33-209
Application
ALUMINIUM NF C33-209 service bundled conductors are used for tributary networks of power buildings and their internal networks.
Characteristics
The bundled conductor cables have aluminum conductors, insulated with XLPE, they have good durability and thermal resistance.
Some other important cable characteristics are :
- Ultraviolet radiation resistance,
- Ozone resistance,
- High dielectric strength,
- Light and easy to handle.
Installation
The NF C11-201 standard´s procedures determine the installation procedures for low voltage overhead lines.
These cables are NOT ALLOWED to be buried, even in conduits.
Marking
- Neutral :
211 NF C33-209 211 « manufacturing number », « metric marks » ink printed.
- Phase 1, 2, 3 :
the identification number is printed and embossed on insulation.
- Pilot wire n°1 : continuous white line is printed on the insulation
- Pilot wire n°2 : no marking
Electrical characteristics
- Rated voltage : 0.6/1 kV
- Test voltage : 4 kV AC
- Resistance to voltage surges : 1.2/50µs with a positive or negative polarity and a peak value of 20 kV.
Low carbon offer
Low carbon at a glance
Characteristics
Characteristics
Construction characteristics
Construction characteristics
Dimensional characteristics
Dimensional characteristics
Electrical characteristics
Electrical characteristics
Mechanical characteristics
Mechanical characteristics
Usage characteristics
Usage characteristics
